Vijay Steels is a trusted supplier and distributor of Mild Steel Beams in Jodhpur, Rajasthan, serving contractors, fabricators, and infrastructure developers with dependable materials and responsive service. We stock a wide range of sizes and sections, ensuring consistent availability for urgent and planned requirements. Our beams are sourced from reputed mills, inspected for dimensional accuracy, straightness, and surface finish, and delivered with transparent test documentation. With quick turnaround, fair pricing, and careful handling, we help projects stay on schedule and within budget. Partner with us for reliable MS Beam supply, professional guidance, and doorstep delivery across Jodhpur and nearby regions.
Vijay Steels mild steel beam supplier and distributor in Udaipur, Rajasthan, Vijay Steels MS beam supplier and distributor in Jodhpur, Rajasthan, Vijay Steels mild steel I-beam supplier and distributor in Jaipur, Rajasthan, Vijay Steels mild steel H-beam supplier and distributor in Jaipur, Vijay Steels structural steel beam supplier and distributor in Udaipur, Vijay Steels ISMB beam supplier and distributor in Jodhpur, Vijay Steels ISWB beam supplier and distributor in Udaipur, Vijay Steels universal beam supplier and distributor in Jaipur, Vijay Steels hot rolled mild steel beam supplier and distributor in Jodhpur, Vijay Steels construction-grade MS beam supplier and distributor in Jaipur, Vijay Steels fabrication mild steel beam supplier and distributor in Udaipur, Vijay Steels heavy-duty MS beam supplier and distributor in Jodhpur.
Mild Steel Beams are generally made from low-carbon steel, containing about 0.15–0.25% carbon. They also have a balanced amount of manganese to enhance strength and toughness, while keeping phosphorus and sulfur levels low to ensure good weldability. Silicon is included to help with deoxidation. The microstructure of these beams is designed to promote ductility and allow for uniform deformation. In terms of mechanical properties, you can expect a yield strength typically between 240–350 MPa, tensile strength around 370–520 MPa, and an elongation of 20% or more, depending on the specific grade and section. They are known for their good notch toughness, consistent hardness, and a stable modulus of elasticity close to 200 GPa. Thanks to their excellent weldability and machinability, Mild Steel Beams are perfect for fabrication, bolting, and making on-site adjustments with ease.
Vijay Steels mild steel beam stockist and distributor in Jaipur, Vijay Steels mild steel beam dealer and distributor in Udaipur, Vijay Steels mild steel beams for industrial sheds supplier and distributor in Jodhpur, Rajasthan, Vijay Steels mild steel beams for warehouses supplier and distributor in Jaipur, Rajasthan, Vijay Steels mild steel beams for infrastructure projects supplier and distributor in Udaipur, Rajasthan, Vijay Steels MS beams for RCC and steel structures supplier and distributor in Jodhpur, Rajasthan
Specifications of Mild Steel Beam
| Parameter | Specification / Options |
|---|
| Applicable Standards | IS 2062 (E250/E350), IS 808 (dimensions), IS 1852 (tolerances); ASTM A6/A36; EN 10025 (S275/S355) |
| Section Types | ISMB/ISWB/IPE/IPN/UB (I-/H-beams) |
| Depth (h) Range | ~100–600 mm (wider on request) |
| Flange Width (b) | ~50–250 mm (section-dependent) |
| Thickness (tw/tf) | Web ~4–20 mm; Flange ~6–25 mm (section-dependent) |
| Unit Weight | ~6–122 kg/m (by section designation) |
| Lengths | 6 m, 9 m, 12 m standard; 15–18 m or cut-to-length on request |
| Dimensional Tolerances | As per IS 1852 / ASTM A6 / EN 10034 (by standard ordered) |
| Supply Condition | Hot-rolled; normalized/normalized-rolled on request |
| Surface Condition | As-rolled black; shot-blasted & primed (red oxide/epoxy) optional |
| Weldability | Good (low C, controlled CEV); preheat based on thickness/CEV |
| Testing & Docs | Mill Test Certificate (EN 10204 3.1); ultrasonic/impact tests if specified |
| End Finish | Mill-cut or gas-cut; deburred on request |
| Typical Applications | Building frames, PEBs, bridges, platforms, crane girders, racking, shipbuilding |
| Brands (India, typical) | SAIL, Tata Steel, JSW, AM/NS India, RINL (as available) |
Chemical Composition of Mild Steel Beam
| Element | IS 2062 E250 | IS 2062 E350 | ASTM A36 |
|---|
| C (Carbon) | ≤ 0.23 % | ≤ 0.20 % | ≤ 0.25 % |
| Mn (Manganese) | 0.50–1.50 % | 0.50–1.60 % | 0.80–1.20 % |
| Si (Silicon) | ≤ 0.40 % | ≤ 0.45 % | ≤ 0.40 % |
| P (Phosphorus) | ≤ 0.040 % | ≤ 0.040 % | ≤ 0.040 % |
| S (Sulfur) | ≤ 0.040 % | ≤ 0.040 % | ≤ 0.050 % |
| Cu (Copper, if specified) | — | — | ≥ 0.20 % (Cu-bearing option) |
| CEV (t ≤ 20 mm, ref.) | ≤ 0.42 | ≤ 0.45–0.47 | ~0.40–0.44 |
Mechanical Properties of Mild Steel Beam
| Property | IS 2062 E250 (Fe 410W) | IS 2062 E350 (≈ S355) | ASTM A36 |
|---|
| Yield Strength, ReH (≤20 mm) | ≥ 250 MPa | ≥ 350 MPa | ≥ 250 MPa (36 ksi) |
| Tensile Strength, Rm | 410–560 MPa | 490–650 MPa | 400–550 MPa |
| Elongation (GL = 5.65√A0) | ≥ 23 % | ≥ 22 % | ≥ 20 % |
| Charpy V-Notch Impact (typ.) | 27 J @ 0 °C (B/C sub-grades) | 27–47 J @ 0 °C (B/C sub-grades) | Not specified (procurement-dependent) |
| Hardness (HBW, indicative) | ≤ ~187 HB | ≤ ~200 HB | ≤ ~187 HB |
| Modulus of Elasticity, E | 200–210 GPa | 200–210 GPa | 200–210 GPa |
| Poisson’s Ratio, ν | 0.27–0.30 | 0.27–0.30 | 0.27–0.30 |
| Density | 7.85 g/cm³ | 7.85 g/cm³ | 7.85 g/cm³ |
Types Of Mild Steel Beams
Vijay Steels MS beams for RCC and steel structures supplier and distributor in Jodhpur, Rajasthan, Vijay Steels IS 2062 mild steel beam supplier and distributor in Jaipur, Rajasthan, Vijay Steels E250 grade MS beam supplier and distributor in Udaipur, Rajasthan, Vijay Steels structural beam sizes and cut-length supplier and distributor in Jodhpur, Rajasthan, Vijay Steels ready stock mild steel beam supplier and distributor in Jaipur, Rajasthan, Vijay Steels bulk order MS beam supplier and distributor in Udaipur, Rajasthan, Vijay Steels mild steel beam price supplier and distributor in Jodhpur, Rajasthan.
Top Supplier and Distributor of Mild Steel Beam in Jodhpur, Rajasthan
As a leading supplier and distributor of Mild Steel Beams in Jodhpur, Rajasthan, Vijay Steels is all about combining a robust inventory with expert selection and dependable logistics to ensure you get the results you need. We stock popular ISMB, ISHB, and custom sections straight from the mills, complete with mill test certificates and thorough dimensional checks. Our dedicated team is here to help you optimize sizes for loading, deflection, and cost-effectiveness, which means less waste and shorter procurement cycles. With our convenient doorstep delivery, bundling options, and clear documentation, your projects can progress more quickly and safely. Plus, our competitive pricing, prompt responses, and ongoing support help build strong, lasting partnerships. Choose Vijay Steels for reliable availability, technical expertise, and timely supply for all your residential, commercial, and industrial construction needs across Jodhpur. Email us at info@vijaysteels.co.in
Uses of Mild Steel Beam
Mild Steel Beams are a go-to choice in civil construction and industrial projects, thanks to their impressive strength, wide availability, and budget-friendly nature. In buildings, they play a crucial role in supporting floors, roofs, mezzanines, balconies, and stairwells, acting as both primary and secondary framing elements. When it comes to infrastructure, you’ll find them in bridges, culverts, pedestrian walkways, and platform structures. In industrial settings, they’re essential for sheds, warehouses, conveyors, gantry beams, crane runways, pallet racking, and equipment skids. They even help bolster solar structures, billboards, boundary gates, and large canopies. Fabricators love using MS Beams because they’re easy to weld, drill, and bolt, which allows for quick assembly on-site, dependable load transfer, and seamless integration with concrete, decking, and facade systems—all while keeping rework to a minimum.
